2PHA*AO-Fx Series

Description :

Name:Gear pump group 2PHA*A0-Fx Series

Model No.:2PHA-D*A0-Fx

Fit:New Holland/Fiat/Kubota Spare parts, Construction, Industrial machinery, Agriculture machinery, Tractor, Crane, Forklift, Heavy Equipment, Transportation

Replace: Parker PGP/PGM Series,GRF group2 series

Manufacturer:KYDAC

Material:Aluminum/Cast Iron

Max pressure:21MPa

Displacement:3~30 cm3/Rev

Online Message Get a Quote

Product Description:

The 2PHA*A0-Fx Series Hydraulic Gear Pump is a compact and efficient external gear pump designed for medium-pressure hydraulic systems. Featuring a lightweight aluminum alloy housing, precision-machined gears, and a specialized Fx flange mounting configuration, this series delivers stable flow output, high volumetric efficiency, low noise operation, and reliable long-term performance.

The 2PHA*A0-Fx Series is widely used in agricultural machinery, forklifts, construction equipment, hydraulic power units, machine tools, material handling equipment, and other mobile or industrial hydraulic systems requiring dependable hydraulic power transmission. External gear pumps of this type are valued for their compact design, stable performance, and ease of maintenance.

Type	Displacement	Control pressure	Control flow	Max.Speed	Min.Speed
		P1	Oconst
(cm³/rev)		bar	L/min	(r/min)	(r/min)
2PHA-3-D*A0-R	3	100…180	2…30	4000	800
2PHA-4-D*A0-R	4			4000	600
2PHA-6-D*A0-R	6			4000	600
2PHA-8-D*A0-R	8			3500	500
2PHA-10-D*A0-R	10			3000	500
2PHA-12-D*A0-R	12			3000	500
2PHA-14-D*A0-R	14			4000	500
2PHA-16-D*A0-R	16			4000	500
2PHA-18-D*A0-R	18			3600	400
2PHA-20-D*A0-R	20			3200	400
2PHA-22-D*A0-R	22			3000	400
2PHA-25-D*A0-R	25			3000	400
2PHA-28-D*A0-R	28			2500	400
2PHA-30-D*A0-R	30			2500	400
